Page Floor Saw

PMF14

Designed for strength, durability and performance. Whether cutting concrete or asphalt, the reinforced steel box frame design adds strength necessary to reduce vibrations while sawing.

Minimizing vibrations enhance the performance of the blade and extend the life of the saw. Consist of the most popular sizes and configurations for the professional.

FLOOR SAW - PMF14/PMF18 SERIES

Designed for strength, durability and performance. Whether cutting concrete or asphalt, the reinforced steel box frame design adds strength necessary to reduce vibrations while sawing. Minimizing vibrations enhance the performance of the blade and extend the life of the saw. Consist of the most popular sizes and configurations for the professional.

Features

  • Dual blade flanges & reversible guard enable right and left hand cutting.
  • Rugged adjustable pointer wheel assembly, adaptable for left and right hand cutting, is durable and accurate.
  • Strong protected frame for easy transportation and to protect engine.
  • Super-rigid box frame ensures straight cuts while resisting warping and vibration--prolongs saw life; extends blade life.
  • Quality shaft bearings for long service life.
  • Easy crank for raising/lowering cutting depth.
  • Comfortable grip handles.
  • Hinged front, lift-up blade guard is designed to provide easy blade replacement.
  • Saw position guide helps ensure straight cuts.
  • Water system provides an optimum flow and volume of water to the blade.

Working Size(mm)

PMF14

Model A B C
PMF14 Series 1560 480 950
PMF18 Series 1460 585 950
Model PMF14H PMF14R PMF14L
Engine Type Honda GX200 Robin EX17 Lombardini LD225
Power kw(hp) 4.1(5.6) 2.9(4.0) 3.5(4.8)
Weight kg(lb) 77(169) 76(167) 89(196)
Max. Cutting Depth cm(in) 11(4.3)
Blade Size cm(in) 30-35 (12-14 )
Depth Adjustment Handle Rotation
Driving Manual Push
Water Tank Capacity L(US gal) 28(7.4)

* We reserve the right to improve or withdraw the specification or product without prior notice.
